Ceiling-mounted AP
WAP2100-T618-V2
- 802.3af/at standard PoE power input
- Energy efficiency design
- 802.11a/b/g/n/ac/wave2/ax/be up to 32 SSID
- Max. 256 concurrent users
- FIT and FAT AP mode
- SNS, SMS and white-list login authentication
- Universal network management
- Cloud platform
- Portal 2.0
Specifications
| Ethernet port | 1-port Gigabit WAN (PoE)
1-port Gigabit LAN |
| Frequency | 2.4GHz + 5GHz |
| IEEE Standard | 802.11 a/b/g/n/ac/wave2/ax |
| Max. Data Rate(Mbps) | 1775 |
| Signal Rate | 575 Mbps (2.4 GHz)
1200 Mbps (5 GHz) |
| MIMO | 2×2/2×2 |
| Transmission Power | < 22 dBm (2.4 GHz)
< 22 dBm (5 GHz) |
| Coverage Radius(m) | <20 |
| Concurrent Clients | 128 |
| Button | 1 RST/LED |
| Power Supply | PoE + 12V DC |
| Power Consumption(W) | 17 |
| Mounting | Ceiling/Wall mouting(Kits included) |
| Dimensions (WxDxH)(mm) | 180×180×26 |
| Weight(g) | 400 |
| Environment | Operating Temperature: 0–50 ℃ (32–122℃)
Storage Temperature: -40–70 ℃ (-40–158 ℃) Operating Humidity: 10–95% RH non-condensing Storage Humidity: 5–95% RH non-condensing |
| Protection Level | IP31 |
