WAP2100-W512
- High-performance Wireless Solutions
- User-friendly Design Details
- Comprehensive Security Features
Specifications
| Mounting method | In-wall |
| Dimensions (HxWxD) | 86×86×36mm |
| Ethernet port | 1 GE WAN (POE supported)
1 GE LAN (dust-proof) |
| PoE power supply | POE input |
| Antenna type | Built-in omnidirectional |
| Antenna gain | 2.4G: 2.5dBi
5G: 2.5dBi |
| Operating frequency bands | 2.4GHz and 5GHz |
| Wi-Fi data rate | 2.4G:2*2 11n 400Mbps
5G-1:2*2 11ac 867Mbps |
| Maximum transmit power | 2.4 GHz: 18 dBm (combined power)
5 GHz : 18 dBm (combined power) The actual transmit power depends on 2.4 GHz: 18 dBm (combined power) local laws and regulations. |
| Modulation | OFDM : BPSK@6/9Mbps,
QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS : DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps MIMO-OFDM (11n): MCS 0-15 MIMO-OFDM (11ac): MCS 0-9 |
| Modulation mode | 11b:
DSS:CCK@5.5/11Mbps,DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM:64QAM@48/54Mbps,16QAM@24 Mbps,QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM: BPSK,QPSK,16QAM,64QAM 11ac: MIMO-OFDM: BPSK,QPSK,16QAM,64QAM,256QAM |
| Power adjustment | Automatic |
| Reset | Supported |
| Status LED | on / Blinking/ error |
| Operating temperature/ Storage temperature | 0ºC~50ºC |
| Operating humidity | 10%~95% (non-condensation) |
| Protection degree | IP41 |
| Power consumption | < 10W |
| MTBF | > 250000H |
| 11ac supported | Working frequency bands
A-MPDU A-MSDU Transmit Beamforming (TxBF) Maximum Likelihood Demodulation (MLD) Maximum Ratio Combining (MRC) Space-Time Block Coding (STBC) Low Density Parity Check (LDPC) |
| 11n supported | Working frequency bands
A-MPDU Transmit Beamforming (TxBF) Maximum Likelihood Demodulation (MLD) Maximum Ratio Combining (MRC) Space-Time Block Coding (STBC) Low Density Parity Check (LDPC) |
| WLAN basics | Maximum users per radio
WPAPSK/WPA2PSK/WPA3 RTS/CTS Guest network Smart device unique SSID Automatic link fault detection and recovery |
| Advanced networking features | Automatic network-wide channel adjustment
Automatic network-wide bandwidth adjustment Automatic network-wide power adjustment |
| Security policy | Encryption
802.11i Authentication User isolation Forwarding security SSID-VLAN binding 802.11w |
| Layer-2 and layer-3 features | IP address configuration
Local forwarding Multicast |
| Advanced Wi-Fi features | 802.11e
Priority Ai QoS |
| Advanced Wi-Fi features | Automatic channel/bandwidth/power selection
Load balancinga 802.11k/802.11v/802.11r AP Steering Band Steering Automatic power control / Packet-by-packet power control Multicast enhancement |
| Installation, management and maintenance | Multicast enhancement
Network pre-deployment Local management with app/Remote manageme nt Cloud AC management Remote maintenance |
